High-temperature retortable high-barrier cast film
-
Chicken Breast, Crab Sticks, Corn, Snacks and More
Performance Characteristics
High Barrier Properties: Preserve the original properties of the product while enhancing food health and safety.
Excellent Flatness: Has good thermal mouldability and minimises leakage when transported and handled
High Clarity: It creates a three-dimensional (3D) effect and enables a full view of the product.
Multilayer Coextrusion: It provides high tensile strength and high puncture resistance.
High Temperature Retorting: It is designed for applications involving high retort sterilization (121°C for 30 minutes).
1.Excellent Barrier Performance
2.Superior slip performance
3.Good Clarity& Gloss
4.High Tensile Strength
5.Excellent Flatness
Corona Treatment: Single-sided Treatment / Double-sided Treatment
Thickness Range: 40-380 μm
Performance Indicator
|
Implementation Standard
|
Unit
|
Reference Value
|
|
Thickness Tolerance
|
GB/T 6672-2001
ISO 4593
DIN 53370
|
μm
|
0 — ±2
|
|
Width Tolerance
|
GB/T 6673-2001
ISO 4592
|
mm
|
0 — +2
|
|
Coefficient Of Friction
|
GB/T 10006-2021
ISO 8295
|
—
|
Customized
|
|
Luminous Transmittance
|
GB/T 2410-2008
ISO 14782
ASTM D1003-21
|
%
|
90-95
|
|
Haze
|
GB/T 2410-2008
ISO 14782
ASTM D1003-21
|
%
|
3-15
|
|
Tensile Strength
|
MD
|
GB/T 1040.3-2006
ISO 527-3
|
N/15mm²
|
≥15
|
|
TD
|
≥10
|
|
Elongation
|
MD
|
GB/T 1040.3-2006
ISO 527-3
|
%
|
≥300
|
|
TD
|
≥300
|
|
Water Vapor Transmission Rate
|
GB/T 26253-2010(38℃/90%RH)
ISO 15106-2
|
g/(㎡·24h)
|
1-15
|
|
Oxygen Transmission Rate
|
GB/T 1038.1-2022(At23℃,Dry,1Atm)
ISO 15105-1
DIN 53380-1
|
cm³/(㎡·24h·0.1Mpa)
|
0.3-5
|
|
Heat-Seal Strength
|
QB/T 2358-1998
|
N/15mm
|
≥5
|
|
Peel Strength
|
GB/T 8808-1988
|
N/15mm
|
≥3
|
IMPORTANT NOTE: The above data has been obtained from our laboratory and is provided for reference only. It must not be used as a basis for operation under specific environments or conditions. Users are kindly requested to test each performance index independently to determine whether the product is suitable or not.During transportation, loading, and unloading, mechanical collisions should be avoided to prevent damage to the surface or end face. Additionally, avoid exposure to sunlight and rain, and store the product in a clean, cool, and dry place.
|
Product Range
|
Structure
|
Max Width(mm)
|
Thickness Range(um)
|
Barrier Properties
|
|
Medium Barrier
|
PA/PE
|
2820
|
40-380
|
OTR≤150cm³/(㎡·24h·0.1Mpa)
WVTR≤15g/(㎡·24h)
|
|
PA/PP
|
|
PE/PA/PE
|
|
PP/PA/PP
|
|
High Barrier
|
PA/EVOH/PE
|
OTR≤5cm³/(㎡·24h·0.1Mpa)
WVTR≤15g/(㎡·24h)
|
|
PA/EVOH/PP
|
|
PE/EVOH/PE
|
|
PP/EVOH/PP
|
|
PE/PA/EVOH/PA/PE
|
|
PP/PA/EVOH/PA/PP
|
|
PP/PA/EVOH/PA/PE
|
