Bioreaction - bag Film
Application

Bioreaction - bag Film


Performance Characteristics
Bioreaction - bag Film: It boasts low extractables, minimal precipitation, outstanding chemical compatibility, and remarkable biological safety. Moreover, it has the remarkable ability to block oxygen, carbon dioxide, and water vapour, among other substances.

Performance
1.Excellent barrier performance
2.Low precipitation

3.Good chemical compatibility and bio - safety

Corona Treatment: N/A

Typical Thickness: 320 μm, 350 μm, 380 μm, 420 μm


Technical Parameter
Performance Indicator
Implementation Standard
Unit Reference Value
Thickness Tolerance GB/T 6672-2001
ISO 4593
DIN 53370
μm 0 — ±2
Width Tolerance GB/T 6673-2001
ISO 4592
mm 0 — +2
Coefficient Of Friction GB/T 10006-2021
ISO 8295
Customized
Luminous Transmittance GB/T 2410-2008
ISO 14782
ASTM D1003-21
% 90-95
Haze GB/T 2410-2008
ISO 14782
ASTM D1003-21
% 5-15
Tensile Strength MD GB/T 1040.3-2006
ISO 527-3
N/15mm² ≥50
TD ≥50
Elongation MD GB/T 1040.3-2006
ISO 527-3
% ≥300
TD ≥300
Water Vapor Transmission Rate GB/T 26253-2010(38℃/90%RH)
ISO 15106-2
g/(㎡·24h) 1-2
Oxygen Transmission Rate GB/T 1038.1-2022(At23℃,Dry,1Atm)
ISO 15105-1
DIN 53380-1
cm³/(㎡·24h·0.1Mpa) 0.3-1
Heat-Seal Strength QB/T 2358-1998 N/15mm ≥40
Peel Strength GB/T 8808-1988 N/15mm ≥15
IMPORTANT NOTE: The above data has been obtained from our laboratory and is provided for reference only. It must not be used as a basis for operation under specific environments or conditions. Users are kindly requested to test each performance index independently to determine whether the product is suitable or not.During transportation, loading, and unloading, mechanical collisions should be avoided to prevent damage to the surface or end face. Additionally, avoid exposure to sunlight and rain, and store the product in a clean, cool, and dry place.
Product Structure
Product range Structure Max Width(mm) Typical Thickness Barrier Properties
Medium Barrier PA/PE 2820 320μm, 350μm, 380μm, 420μm OTR≤150cm³/(㎡·24h·0.1Mpa)
WVTR≤15g/(㎡·24h)
PA/PP
PE/PA/PE
PP/PA/PP
High Barrier PA/EVOH/PE OTR≤5cm³/(㎡·24h·0.1Mpa)
WVTR≤15g/(㎡·24h)
PA/EVOH/PP
PE/EVOH/PE
PP/EVOH/PP
PE/PA/EVOH/PA/PE
PP/PA/EVОH/PA/PP
PP/PA/EVOH/PA/PE
